CLZ series
marine vertical centrifugal pumps have the characteristics of small
volume，tight
weight，
self-suction performance being nice as well as
being handy of installation and operation．
They are
suitable for being used as bilge pumps，
ballast pumps，
fire pumps，
cooling pumps and used for other
apparatus．
The max．
temperature
of the media transferred should not exceed 80℃．
CLZ series
pump can de connected to a wet cyclone according to the requirement of the
customer．The wet cyclone will separate and purify the
liquid flowing from pump’s outlet The separated and purified，
liquid being led to the sealed space will flush away and cool down
the friction point of mechanical sealing，
avoiding particles
m the liquid enlarge the wear-down of the friction point and promote the life-span
of the mechanical sealing．
The flange of pump’s inlet and outlet accords with
the standards of GB9113.3-1988
(PN1.6Mpa)and GB2505-89(PN1.6Mpa,Marine Cast Bronze
Flange)．Please make a note in the，ordering contract
when the standard of the flange of pump’s inlet and outlet being differ from that
above-mentioned．
